Skid Steer Loader

Model:HT35-25

Overall Operating Weight

6000KG

STEERING SYSTEM

TRANSPORT DIMENSION

Steering Angle

±36°

L*W*H

7600×2100×3100mm

Min. turning radius

5018mm

Wheel base

2250mm

Pressure of the system

12Mpa

Min. Ground Clearance

300mm

AXLE

Bucket Capacity

1.3m3

Type

Four wheel drive

Breakout Force

38KN

Final Reducer

Single Stage Final Reducer

Loading Lifting Capacity

2500KG

TRANSMISSION SYSTEM

Bucket Dumping Height

3500mm

TORQUE CONVERTER

Bucket Dumping Distance

1022mm

Model

YJ280

Backhoe Capacity（Width）

0.3m3(620mm)

Type

Single-stage Three Elements

Max. Digging Depth

4100mm

Cooling Method

Oil-cooling Pressure Circulation

Optional Digging Depth

5300mm(digging arm with telescopic)

GEARBOX

Swing Angle of backhoe

180°

Type

Power Transmission

Max. Pulling Force

39KN

Optional Gears

Four Gears Ahead, Four Gears Astern

Wheel tread

1600mm

Max. Speed

35Km/h

Wheel base

2680mm

TYRE

ENGINE

Model

16/70-20

Model

YUNNEI 4102 Turbo

Pressure of Front wheel

0.22 Mpa

Type

In Line，Direct injection，Four-Stroke，Water Cooling

Pressure of Back Wheel

0.22 Mpa

Rated Power

76KW

BRAKE SYSTEM

Optional engine

77.3KW YUCHAI

Service Brake

Air Over Oil Caliper Brake

CUMMINS 74KW 4BT3.9-C100

External Type

CUMMINS EURO3 75KW QSB3.9-C100

Self-regulation

EURO5 YUCHAI or EPA4 CUMMINS

Self-balance

HYDRAULIC SYSTEM

Emergency Brake

Operation Power Implementing brake

Pressure of Hydraulic System

22Mpa

Manual Operation Power Terminating Brake
