Loader

Model:HTS360L

Engine Brand

Briggs & Stratton Engine

Maximum operating height

2490mm

Intended power

13.5KW

Height to bucket pin

1670mm

Nominal speed

3000rpm

Overall vehicle height

1390mm

Number of cylinders

1

Maximum bucket height

2180mm

Intake method

natural

Overall length without attachments

1540mm

Displacement

420CC

Overall length with standard bucket

2160mm

Emission standard

Euro5-EPA

Maximum height unloading angle

139mm

Rated load

200kg

Unloading height

1564mm

Maximum load

300kg

Unloading distance

446mm

Maximum lifting force

350KN

Bucket turning angle at ground level

25°

Travelling speed

0-6km/h

Turning angle of the bucket at maximum

115°

Working three and

9s

Bucket volume

0.06m³

Working system pressure

17-21bar

Operating mass

900kg

Fuel tank volume

5L

Track type

150*36*72mm
